Rotaflex Pumping Units

  1. Slow, Long Strokes:
  Long stroke make high coefficient of fullness, less fluid pounding;Slow period means less wear on downhole equipments and little cost.

  2. Belt Transmission:
  A long life heavy duty belt transmission can absorb the shock during stroke reverse, thus effectively reduce the stress on downhole components to make rod strings run smoothly.

  3. Low Torque Demand:
  The torque demand is greatly reduced due to the short torque arm which is only 0.46m. Thereby, smaller prime mover and gear box may be possible which can cut down energy costs by 10% to 40% comparing to other manual lift system.

  4.Optimum Structure Design, Safety and Convenience:
  Two sets of brake systems with the automatic braking device ensure the units safety absolutely; enclosed unit design makes the units folded up and convenient during shipping, moving safely.

  5.High Reliability and Low Maintenance:
  High reliability by using antifriction bearings, heavy duty belt, heavy load sleeve roller chains, mechanical balance, perfectly lubricating system and self-protection and enclosed unit design ensure to carry load evenly and perfect rigidity through optimum design.

  6.Auxiliary system is fairly complete, not only for high volume production, but also for deep wells low volume production.

  • Type

    SPECIFICATIONS

    1100

    1000

    900

    800

    700

    600

    500

    m Stroke Length

    8

    8

    7.3

    7.0

    6.0

    5.0

    4.5

    t Peak Polished Rod Load

    22.7

    20

    16.3

    14

    12

    10

    8

    min-1 Max of Strokes Per Minute

    4

    4

    4

    4

    4

    5

    5

    min-1 Min of Strokes Per Minute

    Very Low

    t Counterweight Base

    6.1

    4.6

    4.2

    2.7

    2.4

    1.9

    1.7

    t Counterweight-Max Aux.

    8.6

    9.0

    7.2

    7.1

    6.4

    4.8

    3.5

    t Shipping Weight

    26.5

    22

    19.5

    16.5

    15.5

    12.0

    11.0

    External Size(L×W×H)

    7.4×2.6 ×13.4

    7.4×2.4 ×13.4

    6.6×2.4 ×12.4

    6.1×2.1 ×11.8

    5.5×2.1 ×10.8

    5.5×1.9 ×8.9

    5.2×1.9 ×8.2

    Shipping Size(L×W×H)

    13.4×2.6 ×3.1

    13.4×2.4 ×2.8

    12.4×2.4 ×2.8

    11.8×2.1 ×2.6

    10.8×2.1 ×2.5

    8.9×1.9 ×2.5

    8.2×1.9 ×2.5

    Motor power

    75

    75

    55

    45

    37

    22

    18.5

    kN·m Torque of Gearbox

    37

    37

    37

    26

    26

    18

    13

    Working Temperature

    -40℃~+50℃

    Electromagnetism Automatic Braking System

    Yes

    Yes

    Yes

    Yes

    Yes

    N/A

    N/A

    Note: Automatic Braking System is available according to the customer’s requirements.
